MK-400 Stand alone (Bench-top) marking machine

Product code : SKU00042

Stand alone Dot peen marking machine “MK-400” are designed for small quantities and various kinds of marking.
Jeil Mtech (Markmans) “MK-400” has built in controller inside of marking head as Bench top marking machine.
You can even edit marking information with inbuilt keyboard and verify your variable data and setting to front built-in LCD.
It supports actual marking to linear, angular and cylindrical surfaces. (No need other optional program)Any material can be marked from plastic and hardened steel upto HRC 62.

Possible to create marking files on inbuilt keyboard and actual marking data appear to inbuilt screen. Can save and load marking data via USB.

It is possible to visualize the created marking file by preview function on front screen before the actual marking process.

0903 446 042 Get a quote

Model	MK-400
Dimension	248mm (W) X 275mm (L) X 190mm (H)
Marking area	130mm (X) X 100mm (Y)
Weight	12kg , T300 table : 20kg
Available cha. height	1.0 – upto max. depending on Marking Window
Font	Standard 1 & 2, DOT font (Size 5x7), User fonts
Marking Pin	Electromagnetic marking pin
Stroke of marking pin.	Upto Max. 5mm (Constant marking depth)
Available Cha.	Figure, Capital letters, Lower case. Special cha.
Electric	Select 85 ~ 230V, 50/60Hz
Data storage	Inside memory or external USB slot
